Product Overview
Details
The FOXEER action camera is tiny and light at only 49g. It's equipped with an Ambarella A7LS processor and 16MP Sony Exmor R BSI CMOS Sensor. Using 7G optical glass lens of 166°ultra-wide angle, it also has wide, normal, narrow options for selection. 1080P 60 frames per second recording allows you to capture every moment perfectly. You can capture 16MP still photos or time lapse photos at set intervals from 3 to 60 seconds.
The camera features exclusive R&D UAV wireless control capturing technology, you can wirelessly activate the photo/video functions by UAV remote controller (RC handset). recommend class 10 or above Sandisk MicroSD card.
Features
-
Ambarella A7LS processor
The Ambarella A7LS Processor guarantees ultrahighspeed pixel processing, enhanced dynamic range and outstanding color fidelity images.
-
Sony IMX206
The 16MP Sony Exmor R BSI CMOS Sensor reduces the noise and increases the light sensitivity of the camera. Record every epic moment, even in dark environments. Never worry again about missing a great moment, whether light or dark.
-
1080P60fps
FOXEER action camera meets your demand for different image/video quality since it has multiple modes, 1296P30F, 1080P60F, 1080P30F, 720P120F, 720P60F, 720P30F. You can also create time lapse videos easily.
-
UAV remote control
Featured by exclusive R&D UAV wireless control capturing technology, you can wireless activate the photo/ video by UAV remote controller.
- 7G Optical Glass Lens / F2.5 Large Aperture 166° Ultra Wide Angle
-
Tiny and light weight
Only 49 grams
-
High Efficiency Battery
850mah Lithium Polymer
| Foxeer Legend 1 | |||
| Image | Type | 1/2.33” CMOS 16.37 MP (Sony IMX206) | |
| Sensor | Effective Pixels | Approx. 16.35 Mega Pixels (4672 * 3500) | |
| Output Pixels | Approx. 16.76 Mega Pixels | ||
| Lens | Focal Length | Lens f= 3mm | |
| F No. | F= 2.5 | ||
| F.O.V(D) | 166°(H=120° V=89°) | ||
| Focusing | Type | Fixed | |
| Exposure | Control | Programmed AE | |
| Compensation | ±2EV (0.33 EV steps) | ||
| ISO Equivalent | Auto, 100, 200, 400, 800, 1600 | ||
| LED | Modes | No | |
| White Balance | Auto / Cloudy / Daylight / Incandescent | ||
| Shooting | Still Image | Modes: Single Image up to 16M | |
| FHD 1080P | 1206P: 2304*1296P 30fps | ||
| 1080P: 1920*1080P 60/30 fps | |||
| 720P: 1280*720P 120/60/30 fps | |||
| FOV | Wide / Normal / Narrow | ||
| Audio | Mic and Speaker (Mono) Equipped | ||
| Storage | Media | Internal memory: no internal memory | |
| External memory: supporting SDHC Card up to 64GB | |||
| File Format | Photo : JPEG | ||
| Audio : PCM 48KHZ 16bit | |||
| Video : H.264 High Profile Level 4.2 MP4 | |||
| Image Size 5Mp | 16M（4608x3456） | ||
| 12M（4000x3000） | |||
| 8M（3264x2448） | |||
| 5M（2560x1920） | |||
| Video Output | HDMI: Support 1920X1080P60 output With CEC | ||
| Composite: NTSC/PAL | |||
| Time Lapse Function | Video: OFF / 1 Seconds / 2 Seconds / 5 Seconds / 10 Seconds / 30 Seconds / 60 Seconds | ||
| Photo Functions | Auto Shooting ：OFF / 3 Seconds / 5 Seconds / 10 Seconds / 30 Seconds / 60 Seconds | ||
| Language | English | ||
| Interface | USB 2.0 : Recharging/File Transfer | ||
| Power Source | Li-ion rechargeable Battery 850 mAH | ||
| Accessories | USB Cable, AV Cable | ||
| Dimensions (W*H*D) | L: 75mm, W: 37.5mm, H:17mm | ||
| Weight | |||
| Support | Mass Storage Driver | ||
| Windows XP(Service pack 2) or later | |||
| Mac OS X 10.4.11 or later | |||
| System Requirements | |||
| For Windows | *PC with processor better than Pentium 4 3.2GHz | ||
| *Windows XP(Service pack 2) or later | |||
| *Minimum 1 GB System RAM | |||
| *Minimum 256 MB RAM Video Card | |||
| *USB port, CD-ROM drive | |||
| *1024*768 pixels, 32-bit color display compatible monitor | |||
Includes
- 1X Foxeer HD 60fps camera
- 1X USB cable
- 1X FPV Servo Cable
Videos
Rear view camera is the Foxeer Legend 1
