Product Overview
Eachine Goggles One highlights
- Built-in 5.8GHz 40CH receiver (with raceband);
- 5 inch with up to 1080p playback;
- Compatible with wide range of racing quadcopters;
- Perspective: 78 degrees;
- Wide range power input: 7-13V;
- High capacity 1600mAh smart battery;
- Audio output for connecting headphones;
- HDMI input for virtual realty;
- Brightness and contrast adjustment.
Included with the Eachine Goggles One
- Rubber duck antenna;
- HDMI cable;
- Head strap;
- 1600mAh 7.2V battery;
- USB battery charger cable;
- Eachine Goggles One user manual.
Specificaiton:
Brand name: Eachine
Item name: Goggles One FPV Goggles
Frequency: 5.8GHz 40CH (Racebands)
Highest resolution: 1920*1080
Input voltage: 7-13V
Screen size: 5 Inches
Field of View: 78 degrees
Languages: English, German, Japanese, French and other languages
Weight: 320g(without battery)
Supply voltage: 7-8.4V
Audio: Bulit-in audio output for connecting headphones
Support: 5.8GHz analog Input or HDMI Input
Support: brightness, contrast adjustment
Operating temperature: -20Â to 80
Dimensions: 25x20x19 (cm)
                                  Frequency Table | ||||||||
Frequency bands A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 |
Frequency bands B | 5733 | 5752 | 5711 | 5790 | 5809 | 5828 | 5847 | 5866 |
Frequency bands E | 5705 | 5685 | 5665 | 5645 | 5885 | 5905 | 5925 | 5945 |
Frequency bands F | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 |
Frequency bands R | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 |
Feature :
-5.8GHz support analog video input, HDMI high-definition video input
-1920*1080p Highest resolution
-Bulit-in 5.8G, 40 frequency auto search frequency receiver
-Built-in audio volume headphone output(adjustable volume)
-Built-in headset, HDMI jack
-Support brightness adjustment
Package Included:
1 X Goggles One FPV Goggles
1 X 7.4V 1600mAh Smart Battery
1 X HDMI to USB Cable
1 X Android USB Cable
1 X User Manual
