Product Overview
Product Specifications
30 Pin Count
FPC Connector Type (ZIF)
SMD Surface Mount — Solder-On
| Part Type | Keyboard FPC / ZIF Cable Connector (30-pin) |
| Pin Count | 30 pins |
| Connector Type | FPC — Flexible Printed Circuit ZIF (Zero Insertion Force) socket |
| Mounting Type | SMD (Surface Mount Device) — soldered directly to logic board |
| Function | Connects keyboard ribbon cable to MacBook Pro logic board |
| Compatible Models | A2289, A2251, A2338 (2020) | A2141 (2019) | A2337 (2020) |
| Installation | Requires micro-soldering — hot air rework station recommended |
Compatible MacBook Models
MacBook Pro 13" — A2289 (2020) Early 2020 · Intel Core i5 · 2× Thunderbolt 3 ports · EMC 3456 Model identifier: MacBookPro17,1 — Intel variant
MacBook Pro 13" — A2251 (2020) Early 2020 · Intel Core i7/i9 · 4× Thunderbolt 3 ports · EMC 3348 Model identifier: MacBookPro16,2 — Intel 4-port variant
MacBook Pro 13" — A2338 (Late 2020) Late 2020 · Apple M1 chip · 2× Thunderbolt 3 ports · EMC 3578 Model identifier: MacBookPro17,1 — First Apple Silicon MacBook Pro
MacBook Pro 16" — A2141 (2019) Late 2019 · Intel Core i7/i9 · EMC 3347 Also uses the same 30-pin keyboard FPC connector design
MacBook Air 13" M1 — A2337 (2020) Late 2020 · Apple M1 chip · EMC 3598 Shares the same 30-pin FPC connector design
About This Part
The Keyboard FPC Cable Connector is the 30-pin ZIF (Zero Insertion Force) socket soldered directly onto the MacBook Pro logic board that receives the keyboard's flexible ribbon cable. This tiny but critical component is the sole electrical interface between the keyboard assembly and the logic board — if it is cracked, lifted, corroded, or damaged, the keyboard will become partially or completely unresponsive.
Connector damage most commonly occurs during keyboard replacement or topcase swaps when the ZIF locking tab is broken, or following liquid damage where corrosion attacks the fine-pitch solder joints beneath the connector. This replacement connector is surface-mounted to the logic board using a hot air rework station or soldering iron with appropriate flux — a standard component-level repair for trained MacBook board repair technicians.
- 30-pin ZIF socket — exact replacement for the keyboard FPC connector on the logic board
- Compatible with A2289, A2251, A2338 (2020) and A2141, A2337 as noted above
- Resolves keyboard not detected, partial key failure, and no keyboard response
- SMD component — requires micro-soldering for installation
- Each connector inspected and verified prior to shipping
Common Issues This Part Resolves
Keyboard Not Detected MacBook fails to detect keyboard entirely — "No keyboard found" in System Information
Partial Key Failure Specific rows or groups of keys unresponsive while others work normally
Liquid Damage Corrosion Connector corroded after liquid ingress — restores keyboard connectivity after board cleaning
ZIF Tab Broken During Repair Locking tab snapped during keyboard cable removal — connector must be replaced
Lifted / Torn Connector Pads Connector lifted from board during prior repair — pad restoration and new connector required
Post-Topcase Swap Issues Keyboard unresponsive after topcase or keyboard replacement — damaged connector
Key Features
Exact 30-Pin Specification Correct pin count and pitch for the A2289, A2251 and A2338 keyboard cable — guaranteed fit
Pre-Inspected Each connector checked for pin alignment and structural integrity before dispatch
Broad 2020 MacBook Compatibility Covers all three MacBook Pro 13" 2020 variants — Intel 2-port, Intel 4-port, and Apple M1
Cost-Effective Board Repair Component-level fix — far more economical than a full logic board replacement
Who Is This For?
MacBook Board Repair Technicians Component-level repair specialists performing logic board micro-soldering on 2020 MacBook Pros
Apple Repair Shops Repair shops maintaining stock of common MacBook board-level components for fast turnaround
Advanced DIY Repairers Experienced DIYers with micro-soldering equipment tackling board-level MacBook repair
Data Recovery Specialists Restoring keyboard access to a MacBook Pro board during data recovery operations
Installation Requirements — Please Read This is an SMD (Surface Mount) component requiring micro-soldering skills and appropriate equipment for installation. A hot air rework station (such as a QUICK 861DW or equivalent) or a precision soldering iron with flux is required. The logic board pads are extremely fine-pitch and fragile — improper installation can cause permanent board damage.
This part is intended for qualified repair technicians. If you are not experienced with SMD micro-soldering, we strongly recommend having this installed by a professional MacBook board repair specialist. Consult the relevant logic board schematic and boardview before attempting installation.
This part is intended for qualified repair technicians. If you are not experienced with SMD micro-soldering, we strongly recommend having this installed by a professional MacBook board repair specialist. Consult the relevant logic board schematic and boardview before attempting installation.
What's Included
- 1x 30-Pin Keyboard FPC ZIF Connector — MacBook Pro A2289 / A2251 / A2338 compatible
